E-Frac
IntelliFrac
Electrify your Hydraulic Operations!
E-Frac
SMARTER OIL FIELD OPERATIONS

The IntelliFrac electric pumping unit is an electric-powered JR7000QPE Quintuple Plunger Pump that enhances both power and efficiency in hydraulic fracking operations. This unit is compact, highly efficient, and requires very low maintenance. The IntelliFrac fleet reduces overall logistics costs, as a single truck can carry all the necessary equipment for fracking operations. This mobility allows for quick site switches during operations.


The IntelliFrac can be powered from the grid or integrated with the GenSystems Power2Go (Gas Turbine Generator Set)。 The Power2Go system converts available natural gas—such as wellhead gas, LNG, or CNG—into electricity for use in IntelliFrac hydraulic fracturing operations.

Lower your operational costs and enhance efficiency significantly with Jereh. As one of the leading manufacturers of oilfield equipment, we provide customized products tailored to your hydraulic fracturing needs. Contact us for more details.

50%
Smaller Footprint
Fuel
Electricity
Increase
Mobility
ESG
Compliant
Highlights
Runs on electricity- powered by the grid or by GenSystems Power2Go Gas Turbine Generator Set.
Equipped with 7000 HP Plunger Pump
Max. Flow Rate 18.9 BPM
Customizable based on your needs
  • 7000HP Plunger Pump
7000HP Plunger Pump
  • Plunger Dia. (5")

  • Carrier: Trailer

  • Electric Motor: 6,000 HP VF Motor

  • Motor Voltage: 3,300 VAC

  • VFD 6,000 hp

  • Max. Working Pressure: 16,200 psi

  • Max. Flowrate: 18.9 bpm

  • Weight: 128,980 lbs

  • Overall Dimensions: 730 x 102 x 165 in

7000HP Plunger Pump
Applications
